Why hordes get slow
Survivors-likes, bullet heavens and tower defences share one shape: a few kinds of things, each repeated hundreds of times, so every small per-object cost is multiplied by the size of the horde.
| Tip | In one sentence |
|---|---|
| 1. Measure in real play | Log timings while people actually play; fix the biggest measured cost. |
| 2. Pool, don't instantiate | Make it all while loading, then reuse it; nothing is created mid-fight. |
| 3. One owner per kind | A manager updates a list of objects; objects don't each get an engine callback. |
| 4. Fake most lights | Use glowing sprites instead of real lights on bullets and pickups. |
| 5. Collisions as maths | "Who is near this point or line?" is a grid lookup, not a physics job. |
| 6. Share textures | Neighbours batch only if they share a texture and material: use atlases. |
| 7. Draw copies as one | Hundreds of identical small things become one MultiMesh, with no nodes. |
| 8. Only redraw what changed | Redraw only what moved, and render at your art's size. |
| 9. Let the GPU move things | Send start, velocity and time; the shader moves it, no script. |
| 10. Load early, and don't change the gameplay | Warm up shaders and pools while loading; keep the gameplay the same. |
All of this is GDScript
Every technique here is written in plain GDScript, with Godot's shader language for the GPU parts. There's no C#, no C++ module and no GDExtension. That was partly a constraint (we ship a web build, and C# web export wasn't an option for us). In our logs the slow part was rarely the GDScript itself. It was asking the engine to do one small thing per object, hundreds of times a frame. Changing the shape of that work is what moved our numbers.
Words we use
_draw().Measure in real play
On night 11 our frame rate fell from 48 to 32 fps as the horde passed about 120 enemies. The log showed why: past that point every frame ran two physics ticks instead of one, so all per-enemy work doubled. We would not have guessed that.
Do this
- Build a tiny in-game logger. Once per second, write a CSV row: fps, worst frame, physics ms, draw calls, node count, how many enemies, bullets and pickups are alive, and a timer around each big system.
- Let people play normally, then read the file. Lag shows up where it really happens: wave 11, 200 enemies, one particular spell.
- Build a benchmark scene too: a scripted fight you can re-run the same way every time. Make it answer one question, with switches to turn hits, trails or visuals off one at a time.
Watch out
- A busy machine lies. We saw one benchmark swing 3× (9.4 vs 3.0 ms) from background load alone. Run A, then B, then A again.
- Headless runs measure scripts only. Draw calls, lights and batching need a real window.
- Averages hide stutters. Always log the worst frame too.
- F5 is slower than your game. The editor's debugger made GDScript 2–3× slower: 31–35 ms a frame against 11–19 ms.
- Test the build players get: a release export, with an opt-in log flag (
-- --perflog).
extends Node var _file: FileAccess var _acc := 0.0 var _worst := 0.0 func _ready() -> void: var path := "user://perf_%d.csv" % Time.get_unix_time_from_system() _file = FileAccess.open(path, FileAccess.WRITE) _file.store_line("t,fps,worst_ms,physics_ms,draw_calls,nodes,enemies,bullets") func _process(delta: float) -> void: _worst = maxf(_worst, delta * 1000.0) _acc += delta if _acc < 1.0: return _file.store_line("%d,%d,%.1f,%.2f,%d,%d,%d,%d" % [ Time.get_ticks_msec() / 1000, Performance.get_monitor(Performance.TIME_FPS), _worst, Performance.get_monitor(Performance.TIME_PHYSICS_PROCESS) * 1000.0, Performance.get_monitor(Performance.RENDER_TOTAL_DRAW_CALLS_IN_FRAME), Performance.get_monitor(Performance.OBJECT_NODE_COUNT), get_tree().get_node_count_in_group(&"enemies"), get_tree().get_node_count_in_group(&"bullets")]) _acc = 0.0; _worst = 0.0
var t0 := Time.get_ticks_usec() _update_all_enemies(delta) enemy_ms_total += (Time.get_ticks_usec() - t0) / 1000.0 # average it into the next CSV row
Pool, don't instantiate
Creating scenes mid-fight is one of the most common causes of hitches. Make what you'll need before the fight, then reuse it.
The problem
instantiate() builds the node tree, runs _ready() and registers with physics and rendering; queue_free() tears it down again. Fifty of those in one frame (a shotgun spell, a wave dying) is a visible spike.
The fix
Keep a free list per scene, filled while loading ("prewarm"). In the fight, acquire a parked node and release it when done. Nothing is created or freed mid-fight, and a counter proves it.
class_name Pool extends RefCounted var _free := {} # scene path -> Array of parked nodes (out of the tree) var instantiations := 0 # after prewarm this must NOT move during a fight: test it func prewarm(scene: PackedScene, count: int) -> void: # behind the loading screen for i in count: instantiations += 1 _free.get_or_add(scene.resource_path, []).append(scene.instantiate()) func acquire(scene: PackedScene) -> Node: var list: Array = _free.get_or_add(scene.resource_path, []) if list.is_empty(): # a miss: counted, logged, never a crash instantiations += 1 return scene.instantiate() return list.pop_back() func release(node: Node) -> void: node.deactivate() # YOUR method on the bullet, not built-in: hide, collision off, still in the tree node.reset() # YOUR method too: clear this life's hit list, timers, tint... node.get_parent().remove_child(node) _free[node.scene_file_path].append(node) # the scene it was made from
Rules we learned the hard way
- Author the scene inert (hidden, collision off) so fresh and recycled nodes start identical;
activate()only after parenting. - Write every visual setting on every reuse, defaults included: a recycled fireball otherwise keeps its glow.
- Reset physics interpolation after showing the node: Godot ignores it on a hidden node, and the bullet slides in from where it last died.
- Size the prewarm from the design (projectiles per cast × casts per second × seconds each one lives). Log a miss instead of capping the spell, and free parked nodes on exit.
One owner per kind of thing
Instead of giving every bullet its own _process, let one manager node update them all in one loop.
func _physics_process(delta): position += velocity * delta life -= delta if life <= 0.0: pool.release(self) # × 300 bullets = 300 callbacks a tick
var slot := -1 # index in the manager's list # no _physics_process any more func step(delta) -> void: position += velocity * delta life -= delta if life <= 0.0: manager.release(self)
var live: Array[Bullet] = [] func add(b: Bullet) -> void: b.set_physics_process(false) b.slot = live.size() live.append(b) func release(b: Bullet) -> void: var last := live[live.size() - 1] live[b.slot] = last # the last one fills the hole: O(1), no shifting last.slot = b.slot live.pop_back() b.slot = -1 pool.release(b) func _physics_process(delta: float) -> void: if delta <= 0.0: return # paused (time_scale 0): costs nothing var i := live.size() - 1 # backwards: a bullet that dies is replaced by one already updated, never skipped or doubled while i >= 0: if i < live.size(): # a step can release more than one bullet, so the list may have shrunk live[i].step(delta) i -= 1
- Share drawing the same way. If 200 enemies each show a status icon, one drawer can loop over them in a single
_draw()instead of 200 canvas items. - No allocation per tick. Reuse packed arrays; build no dictionaries or lambdas in hot loops.
- A pause should cost nothing. If you pause with
time_scale = 0(we do, for menus and level-up choices), managers should return at once rather than move 400 objects by zero distance.get_tree().pausedalready skips pausable nodes for you. Check every kind of object: our bullets and enemies stopped, but area spells and beams kept sweeping at zero speed and cost 6–14 ms a frame on the level-up screen.
Fake most lights
We once measured 880 pickup lights costing about 5 ms on their own. A glowing bullet looks great; a real light on every one is a very expensive way to get it.
The problem
In Godot's 2D renderer a light adds drawing work to every sprite it touches, and each sprite has a cap on how many lights can reach it. Fifty lit bullets flying through a crowd multiply the cost of the crowd.
The fix
We used real lights for two jobs. For the floor glow, use a soft round sprite with additive blending; every glow shares one texture and material, so they batch. To keep sprites readable when night darkens the screen (a CanvasModulate), have their shader multiply their colour by the opposite amount: if night is 50 % dark, they brighten ×2, so they end up looking normal.
Bullet (Area2D) ├─ Sprite2D ├─ PointLight2D # floor light └─ PointLight2D # night readability # 2 lights × 50 bullets = 100 lights
Bullet (Area2D) ├─ Sprite2D # lifted.gdshader └─ Glow # soft circle, floor_glow # 0 lights; all glows share 1 material
shader_type canvas_item; render_mode blend_add, unshaded; uniform float gain = 0.05; // glow brightness void fragment() { // COLOR already = modulate × texel COLOR = vec4(COLOR.rgb * COLOR.a * gain, 1.0); }
shader_type canvas_item; // declared in Project Settings → Shader Globals global uniform vec4 night_lift; void fragment() { COLOR.rgb *= night_lift.rgb; }
# ambient = your night CanvasModulate colour; the 0.4 caps the boost at 2.5× var k := 1.0 / maxf(ambient.r, 0.4) var lift := Vector4(k, k, k, 1.0) RenderingServer.global_shader_parameter_set(&"night_lift", lift)
Gotchas
- In a Godot 4 canvas shader
COLORalready holds the texel; samplingTEXTUREagain darkens the sprite. render_mode unshadedignores lights, but not aCanvasModulatetint.- Shader colour can go above 1.0, so a lifted sprite survives the night's darkening.
Collisions as maths
If all you need to know is "which enemies are inside this circle" or "what did this bullet pass through", a simple grid answers it far more cheaply than a physics engine.
The problem
Every enemy and every bullet is an Area2D. The physics engine pairs them, sorts them and sends a signal per contact. In our game, enemies overlapping the player were 54 % of all enemy cost, and 300 bullets through 240 enemies cost 7.9 ms with hits on against 4.9 ms with hits off.
The fix
Once per tick, drop each enemy into a grid of 64 px cells. To check a shape, visit only the cells it covers and do an exact distance test on those few. Enemies leave the physics engine entirely; their hit logic doesn't change.
const CELL := 64.0 const MAX_R := 24.0 # biggest NORMAL enemy (bosses: see the gotcha below) var cells := {} # Vector2i -> PackedInt32Array of enemy indices # simplified for reading; in a hot loop, reuse the arrays instead of making new ones each tick func build(pos: PackedVector2Array) -> void: cells.clear() for i in pos.size(): var key := Vector2i(floori(pos[i].x / CELL), floori(pos[i].y / CELL)) if not cells.has(key): cells[key] = PackedInt32Array() cells[key].append(i) # every enemy touching the segment a->b swept with radius r (a moving bullet) func query_capsule(a, b, r: float, pos, radius, out: Array) -> void: var box := Rect2(a, Vector2.ZERO).expand(b).grow(r + MAX_R) var lo := Vector2i((box.position / CELL).floor()) var hi := Vector2i((box.end / CELL).floor()) for cy in range(lo.y, hi.y + 1): for cx in range(lo.x, hi.x + 1): for i in cells.get(Vector2i(cx, cy), PackedInt32Array()): var c := Geometry2D.get_closest_point_to_segment(pos[i], a, b) if c.distance_to(pos[i]) <= r + radius[i]: out.append(i)
When a boss shows up
Swapping physics for maths must not change how the game plays, and a grid has one trap that only shows up in boss fights.
_now.clear() grid.query_capsule(prev_position, position, radius, enemy_pos, enemy_radius, _now) # remember enemies by a STABLE id, never by list index: with swap-remove, an index can # point at a different enemy next tick (a missed or a double hit) _now_ids.clear() for i in _now: var id := enemy(i).get_instance_id() _now_ids[id] = true if not _inside_ids.has(id): on_hit(enemy(i)) # only NEW arrivals hit; same handler as before _inside_ids = _now_ids.duplicate()
Gotcha we hit: one huge monster slows every query
The trap. A big monster centred in a cell outside your search can still overlap your shape, so every query has to look past its own reach by the radius of the biggest monster. The natural way is one global maximum, rebuilt each tick. Then a single boss joins the fight, and every bullet's query, even one on the far side of the screen, starts scanning extra cells.
How we found it. Our horde fights ran smoothly while the final boss stuttered. A boss has a ~45 px radius against 11–24 px for everyone else, and there were 600–700 bullets in flight against it.
The fix, measured: 600 bullets, 60 enemies and one boss went from 17.4–18.3 ms to 15.5–15.7 ms of physics per frame (about 2 ms, ~13 %). Real, but not the whole story: the rest of that fight's cost was hit processing.
const BIG_RADIUS := 32.0 # ~half a cell for i in count: if radius[i] > BIG_RADIUS: big.append(i) # bosses, giant elites continue bucket(i) max_r = maxf(max_r, radius[i]) # every query: its cells, then the few big ones for i in big: if rect.grow(radius[i]).has_point(pos[i]): out.append(i)
Before you ship the swap
- Test with your biggest monster. 240 small enemies never show this.
- Call your existing hit functions; only the "who did I touch" source changes.
- Never add or remove physics objects inside a physics callback; queue them.
- Cap catch-up steps (Physics → Common → Max Physics Steps per Frame; we use 2) so one slow frame can't snowball.
Draw copies as one
Got hundreds of the same small thing (pickups, sparks, trail segments) that don't need to sort in front of or behind other objects? Stop giving each one a node.
var mm := MultiMesh.new() mm.transform_format = MultiMesh.TRANSFORM_2D mm.use_colors = true mm.use_custom_data = true # 4 free floats per instance for the shader mm.mesh = quad_mesh_built_from_2d_vertices # see gotchas mm.instance_count = 400 var ci := RenderingServer.canvas_item_create() RenderingServer.canvas_item_set_parent(ci, get_canvas_item()) RenderingServer.canvas_item_set_material(ci, pickup_material.get_rid()) RenderingServer.canvas_item_add_multimesh(ci, mm.get_rid(), pickup_texture.get_rid()) RenderingServer.canvas_item_set_custom_rect(ci, true, Rect2(-1e7, -1e7, 2e7, 2e7)) RenderingServer.canvas_item_set_interpolated(ci, false) # write a slot only when that pickup CHANGES (lands, gets collected), never every frame mm.set_instance_transform_2d(slot, Transform2D(0.0, landed_at)) mm.set_instance_custom_data(slot, Color(land_time, bob_phase, 1.0, 0.0))
uniform float now; // game clock, set on physics ticks void vertex() { float age = now - INSTANCE_CUSTOM.x; float bob = round(sin(TAU * (1.2 * age + INSTANCE_CUSTOM.y)) * 2.0); VERTEX.y -= bob * INSTANCE_CUSTOM.z; } // resting pickups cost zero script
Trails, the same way
A Line2D per bullet is a draw call per bullet. Instead, keep a ring of segment slots in one MultiMesh: each tick a bullet writes one segment stamped with the time, and the shader tapers and fades segments by age. Whole frame in our 300-arrow benchmark: 13.7 → 5 ms, and 316 → 28 draw calls.
| Gotcha | Cause → fix |
|---|---|
| Everything vanishes off screen | The visibility box was measured while every instance sat at (0,0) → custom world-sized cull rect (above). |
| Streaks on reused slots | Interpolation blended a slot from its previous owner → interpolation off, blend by hand if needed. |
| Upside-down sprites | A 3D QuadMesh has y-up UVs → build the quad from 2D vertices with explicit UVs. |
| Tests read nonsense | Headless Godot stores no MultiMesh data → keep a CPU copy of what you wrote and test that. |
Only redraw what changed
Godot keeps a canvas item's draw commands until you ask it to redraw. A _draw() that runs every frame throws that away and pays for the whole picture again, even when almost nothing moved.
The problem
Our skill-tree screen is a big web of hexes, threads, level notches, icons, prices and names. A few nodes hold an animated liquid, so the whole web called queue_redraw() every frame. Fully upgraded, that cost 49.9 ms a frame (36 ms of it GDScript re-issuing the same commands), and 116 ms at 4× the nodes, for a screen that barely moves.
The fix
Cut the still part into tiles, one canvas item each, and re-record a tile only when something in it changes. Pan and zoom just move or scale the tiles. A thin live layer redraws every frame, but only what really animates: the selection, the liquid, a burst, a pulse.
class Tile extends Node2D: # one canvas item = one retained command list var ref_zoom := 1.0; var ref_centre := Vector2.ZERO # the camera it was recorded with func _draw() -> void: web.draw_tile(self) # runs ONLY after queue_redraw() func _process(delta) -> void: for t in tiles: if t.dirty: t.queue_redraw() # data changed in this tile var k := camera.zoom / t.ref_zoom # camera = your own pan/zoom state (zoom is a float here) t.scale = Vector2(k, k) t.position = screen / 2 - k * screen / 2 + (t.ref_centre - camera.centre) * camera.zoom live_layer.queue_redraw() # the few things that really animate
| Fully upgraded skill tree, measured | Before | After |
|---|---|---|
| Today's 87 nodes | 49.9 ms/frame | 10.7 ms |
| 4× the nodes (a bigger tree later) | 116 ms/frame | 15.2 ms |
| Panning across it | a full redraw every frame | 0 redraws |
The same idea, one level up: render at your art's size
With the canvas_items stretch mode, Godot draws at the screen's resolution. A 4K monitor is about 9× the pixels of a 1280×720 design, and every glow and full-screen shader pays for each one (on our test PC, ~8 ms of GPU work per frame, with the fans to match). The viewport mode renders at the design size and scales the finished frame up. That's crisp for pixel art, though text gets chunkier. We made it a setting, so players choose:
get_tree().root.content_scale_mode = Window.CONTENT_SCALE_MODE_VIEWPORT # "Performance (720p)" get_tree().root.content_scale_mode = Window.CONTENT_SCALE_MODE_CANVAS_ITEMS # "Sharp (native)"
Let the GPU move things
Most bullets fly in straight lines. If the graphics card knows where one started, how fast it's going and when it left, it can draw it in the right place every frame without any help from your scripts.
// INSTANCE_CUSTOM = (velocity.x, velocity.y, anchor_time, is_live) uniform float flight_now; // set once per frame by the manager vec2 fly(vec2 v, vec4 c, mat4 model) { if (c.w < 0.5) return v; // ordinary sprites using this shader: untouched float t = max(flight_now - c.z, 0.0); mat2 lin = mat2(model[0].xy, model[1].xy); // VERTEX is still in mesh space here, return v + inverse(lin) * (c.xy * t); // so turn the world offset back into it } // --- in each bullet shader, not in the include --- #include "res://flight.gdshaderinc" void vertex() { VERTEX = fly(VERTEX, INSTANCE_CUSTOM, MODEL_MATRIX); }
func after_step(b, prev_pos: Vector2, dt: float) -> void: var predicted := b.anchor_pos + b.anchor_vel * (clock - b.anchor_t0) if b.look_changed or predicted.distance_squared_to(b.position) > 0.0025: # = (0.05 px)² # lay the anchor on the PREVIOUS tick, with this step's real velocity write_anchor(b, prev_pos, (b.position - prev_pos) / dt, clock - dt) func _process(_delta) -> void: # one tick behind + the fraction = Godot's own smoothing material.set_shader_parameter(&"flight_now", clock - last_dt + Engine.get_physics_interpolation_fraction() * last_dt)
Why "one tick behind"
With physics interpolation on, Godot draws a moving object between its previous and current tick. Running the shader clock the same way keeps GPU-moved bullets glued to everything the engine draws, like their trails.
Stay safe
Guard the code with a per-instance flag so other sprites sharing the shader are unaffected, and let anything the fast path doesn't understand keep drawing the old way.
What we measured, and where it backfired
- ~800 glowing bullets (body + halo + floor glow each): draw calls fell from ~1,150 to ~480.
- Frame time stayed within our benchmark's noise, and at 300 plain arrows nothing changed: identical sprites with one material already batch in Godot.
- Then real play bit us: most of our bullets home, orbit or boomerang, so they bent every tick and were rewritten every tick: 4–6 ms a frame, worse than plain nodes. Now only straight-flying bullets go through it.
Load early, and don't change the gameplay
No first-time stutters
- Warm up shaders. A material compiles the first time it's drawn, causing a hitch on the first fireball. Draw each effect in view for a few frames while an opaque loading screen covers it. Off-screen items are culled and never compile.
- Prewarm pools from the design. Work out how many of each object a maxed-out build can have; create them while loading. Log any shortfall.
Faster, but plays the same
- Keep old objects as the source of truth while other code reads them; move only the expensive part (e.g. the drawing).
- Write the rules as tests: "hits once on entry", "pickups freeze when paused".
- Give players a renderer choice. Our Windows build defaults to Direct3D 12 (
rendering_device/driver.windows). Rare 100–600 ms stalls where neither our code nor rendering was busy usually mean a GPU pipeline compiling, and drivers differ in how they handle that.--rendering-driver vulkanswitches renderer at launch; Steam launch options can offer it as a second "Play" entry.
# runs while the loading curtain (an opaque UI layer on top) still hides the world func warm_up(effects: Array[PackedScene], at: Vector2) -> void: for scene in effects: var fx := scene.instantiate() fx.position = at # IN VIEW (e.g. the player's spot): culled items never compile warm_root.add_child(fx) for i in 4: await get_tree().process_frame # let every pipeline compile warm_root.queue_free() # then lift the loading curtain
Think less often than you move
Movement must run every tick or the horde stutters; deciding where to go needn't. Two halves of the horde think on alternate ticks (30 Hz), each handed the time since its last think, so cooldowns keep real time. Bosses and monsters mid-wind-up still think every tick, where a lag would show.
_think_dt += delta _think_n += 1 if _think_n >= stride or busy or not brain.staggers(): # stride 2 = 30 Hz; bosses say no _think_n = 0 brain.think(self, _think_dt) # the banked time, so cooldowns keep real time _think_dt = 0.0 # at spawn: _think_n = 0 or 1, alternating, so the two halves take turns
What it bought, and two lessons next to it
- Worth it, not magic. A think was 1.85 of a monster's 8.7 µs: ~0.9 ms a tick saved at 1000.
- A stagger must survive deaths. Our separation checked half the horde per tick, but any death forced a full pass, and something dies every tick. Moving each saved result with its monster: 5.4 → 2.9 ms.
- Browsers are slower (1.4–1.7× in Chrome): a
.websetting override gives web a smaller horde.
Your checklist
| If you find… | Try… |
|---|---|
| A light on every bullet or pickup | Additive glow sprite + a night-lift shader uniform |
A Line2D trail per bullet | Trail segments in one MultiMesh, faded by age |
instantiate() / queue_free() mid-fight | A pool, prewarmed while loading |
_process on every pooled object | One manager looping over a list |
Area2D on every enemy and bullet | A spatial grid + circle/capsule maths |
| One image per animation frame | A padded texture atlas |
| Hundreds of identical small sprites | A MultiMesh on the RenderingServer |
| Script moving every bullet every frame | An anchor in instance data; rewrite on change |
| A stutter the first time an effect plays | Shader warm-up while loading |
queue_redraw() every frame on a big, mostly still screen | Retained tiles + a small live layer |
| A 4K screen drawing 720p art | A render-quality option (viewport stretch) |
| Every monster deciding every tick | Think at 30 Hz in alternating halves; move every tick |
| A web build with the desktop horde | A .web project-setting override with a smaller cap |
| Timings taken with F5 | Re-measure without the debugger, or in a release build |
| "It just feels laggy" | A perf log from real play; fix the biggest number |
Written by the team at Naio Games, an indie game studio, while optimising our Godot 4 game Hexwright. Three things here haven't had a full playtest yet: Tip 9's straight-bullets-only drawing, Tip 7's pickup MultiMesh and 30 Hz thinking. Everything else was measured on our own machine, so your numbers will differ.
